Fuel Injection Pump Head and Rotor Kit | Sparex Part No.S.105968?6.0 kg

Case IH Motor D239, Bosch Equivalent
Product Specifications
Automatic advance range: -1? to +5?
Brand: Sparex
Classification ID: 7323
Engine Manufacturer: Case IH Motor
Engine Model: D239, Bosch Equivalent
Fuel lubrificated: For test: Calibration Oil ISO4113 For operate: diesel fuel
Hydraulic Timing Device: Yes
Maximum Peak Injection Pressure (bar): 500
Maximum Plunger Stroke (mm): 1.5
Maximum Power per Engine Cylinder (kw): 20
Maximum Pump Speed rpm: 2500
Mechanical Governor: Yes
Number of Plungers: 2
Number of Pumping Outlets: 4
Plunger Diameter (mm): 9
Pressure (bar): 0.1
Pump rotation: Anti-Clockwise
Related products: 105973, 44020, 44021
Tariff Code:8413308090
Temperature range: -20?C to +88?C
Suitable For Infomation
Case IH / International Harvester?743, 743XL, 745, 745S, 745XL, 844S, 844XL, 845, 845XL
Manufacture Information
Bosch 0460304249?Case IH / International Harvester?3228166R91, 3228166R91EX
