Gates Hydraulic Hose – 5/8” 2SC 2 Wire Compact (Roll) | Sparex Part Number: S.118126?0.69 kg

Brand: Gates
Burst pressure (bar): 10048
Burst pressure (psi): 15200
Construction: 2 Wire
Hose inner ? (ins): 5/8
Hose outer ? (mm): 24.1
Maximum Working Pressure (bar): 262
Maximum Working Pressure (psi): 3800
Minimum Bend Radius (mm): 75
Nominal I.D.: DN16
Pack Type: Roll
Reference: 10M2T
Roll length (M): 30
Specification: ISO 11237 2SC R16S , EN 857 2SC , SAE 100R16
Tariff Code: 4009210000
Type: 2SC 2 Wire Compact

Specifications
Manufactures Specifications
Brand: Gates?Burst pressure (bar): 10048?Burst pressure (psi): 15200?Construction: 2 Wire?Hose inner ? (ins): 5/8?Hose outer ? (mm): 24.1?Maximum Working Pressure (bar): 262?Maximum Working Pressure (psi): 3800?Minimum Bend Radius (mm): 75?Nominal I.D.: DN16?Pack Type: Roll?Reference: 10M2T?Roll length (M): 30?Specification: ISO 11237 2SC R16S , EN 857 2SC , SAE 100R16?Tariff Code: 4009210000?Type: 2SC 2 Wire Compact
