Track Rod, Length: 100mm – S.70734?0.3 kg

? A (mm): M22 x 1.5 RH, ? B (mm): M16 x 1.5, ? C (mm): 20 – 18mm, D (mm): 24mm.
Brand: Sparex
Inner side thread ? A (mm): M22 x 1.5 RH
Length (mm): 100
Outer side thread ? B (mm): M16 x 1.5
Taper C (mm): 20 – 18
Taper length D (mm): 24
Tariff Code:8708949900
Thread length E (mm): 24
Type: Male Thread – Straight

Specifications
Manufactures Specifications
Brand: Sparex?Inner side thread ? A (mm): M22 x 1.5 RH?Length (mm): 100?Outer side thread ? B (mm): M16 x 1.5?Taper C (mm): 20 – 18?Taper length D (mm): 24?Tariff Code:8708949900?Thread length E (mm): 24?Type: Male Thread – Straight
Suitable For Information
This product is not associated with any particular make or model
OEM Manufacture Information
Fiat?3130044, 512138?Long Tractor?TX17334?Universal Tractors?512138, 3130044, 31 30 044
